Service Manual
Storm³
As at: 07.03.02 Page 51
Red LEDs in battery charger display and status display are blinking, drive mode display
shows horizontal bar.
Check Possible cause: Immediate measure: Further measure(s):
• Battery
discharged or
defective.
• Charge or replace
battery.
• See battery
charger instruction
manual.
11.3.1 Error codes
The ACS electronic system is capable of carrying out a self-test and of rectifying some errors
automatically. In this case the status display will stop blinking. To do this switch the remote on
and off several times. Wait approx. 5 seconds each time before switching the remote on again.
If the error is not corrected by this process, localise the error using the blink codes listed below.
Joystick box status display blink codes
Blink code:
Meaning: Immediate measure: Further measure(s):
1 x blink
Module defective. -
• Talk to your
dealer.
2 x blink
Accessory error (e.g.
bulb short-circuit)
• Check accessory
part connections
• Check accessory
parts
• Talk to your
dealer.
Lifter raised.
• Lower lifter
completely.
-
3 x blink
Fault in right-hand
motor. Connection
loose/defective.
• Check plug
connections.
• Talk to your
dealer.
4 x blink
Fault in left-hand
motor. Connection
loose/defective or
motor defective.
• Check plug
connections.
• Talk to your
dealer.
5 x blink
Fault/brake fault on
right-hand motor.
Connection
loose/defective or
motor defective.
Microswitch defective.
• Check plug
connections.
• Check
microswitch.
• Talk to your
dealer.
Motors disengaged
• Engage motors
turn the remote
on and off
-
6 x blink
Fault/brake fault on
left-hand motor.
Connection
loose/defective or
motor defective.
• Check plug
connections.
• Talk to your
dealer.
7 x blink
Battery fully
di h d
• Pre-charge • Talk to your
