Invacare Storm 3 - 6 Joystick box error codes

Storm³
Service Manual
Page 16 As at:07.03.02
6 Joystick box error codes
Before assessing the error codes, carry out the following test:
• Turn the remote on and off several times. Wait approx. 5 seconds before switching on.
The test checks whether the error can be automatically rectified by the electronics, and if
necessary deactivates the blinking status display at the remote. If this is not the case, you can
locate the fault using the blink codes as follows:
• turn the remote on and off
• check which blink code is showing by counting
• wait for the blink code pause (approx. 2-3 seconds)
• re-count the code.
Blink code: Meaning: Immediate measure:
1 x blink
Module defective - Replace module
chapt. 11.4.2
2 x blink
Accessory error (e.g.
bulb short-circuit)
Lifter raised
Backrest not in driving
position
• Check accessory
connections, check
accessories
• Lower lifter
completely
• Put backrest in
driving position
Check lighting
chapt. 10
-
-
3 x blink
Fault in right-hand motor.
Connection
loose/defective or motor
defective
• Check connecting
plugs
Check drive unit /
battery chapt.
8.3.2 / 9.2
4 x blink
Fault in left-hand motor.
Connection
loose/defective or motor
defective
• Check connecting
plugs
Check drive unit /
battery chapt.
8.3.2 / 9.2
5 x blink
Fault/brake fault on right-
hand motor. Connection
loose/defective or motor
defective
Microswitch defective
• Check connecting
plugs
• Check microswitch
and engaging
mechanism
Check drive unit /
battery chapt.
8.3.2 / 9.2
-
6 x blink
Fault/brake fault on left-
hand motor. Connection
loose/defective or motor
defective.
• Check connecting
plugs
Check drive unit /
battery chapt.
8.3.2 / 9.2
7 x blink
Completely discharge
battery
• Pre-charge battery
Check battery
chapt. 9.2
8 x blink
Battery voltage too high
• Switch light on if
necessary
• Check battery
charger
Check battery
chapt. 9.2
-
