Invacare Storm 3 - Service Work to Frame (Chassis)

Service Manual
Storm³
As at: 07.03.02 Page 19
4 4 G10103 WASHER 8.4 X 25 X 2
5 4 1419233-0003 HEADED BUSH
6 1 1419341
CHASSIS WITH LIFTER & BATTERY CASE ASSY.
GREEN
6 1 1421681
CHASSIS WITH LIFTER & BATTERY CASE ASSY.
SILVER
6.1 1 1417949-
1101060
CHASSIS GREEN PREASSEMBLED
6.1 1 1417949-9006 CHASSIS SILVER PREASSEMBLED
6.2 1 1418527 LIFTING UNIT PREASSEMBLED
6.3 1 1417955-9005 BATTERY FRAMES PREASSEMBLED
7 4 1419254 ANGULAR BALL BEARING 7202B 2RS
8 1 1422049-9005 FRONT FIXING LH
9 1 1422050-9005 FRONT FIXING RH
10 4 D60178 HEXAGON BOLT M8 X 12
11 4 G00107 WASHER 8.4 X 17 X 1.6
12 1 1421022-9005 TAXI STRAP
13 2 G00117 WASHER 10.5 X 21 X 2
14 2 D00094 HEX BOLT M10 X 50
15 1 1419333 BACK LIGHT SUPPORT LH
15 1 1421815
LIGHT SUPPORT LH WITH LUGGAGE CARRIER
CUTOUT
16 1 1419334 BACK LIGHT SUPPORT RH
16 1 1421814
LIGHT SUPPORT RH WITH LUGGAGE CARRIER
CUTOUT
17 2 1421650-9005 SIDE FIXING
- 4 D90187
CHEESE HEAD SCREW WITH ALLEN KEY HEAD M6
X 20
- 4 G00115 WASHER 6.4 X 12.5 X 1.6
8.1.1 Service work to frame (chassis)
Note:
Repair work to the frame (chassis) is easier to carry out if the complete seat unit has
been dismantled beforehand (see page 56, chapt. 12.1.1).
"
