Service Manual
Storm³
As at: 07.03.02 Page 35
9.1.6 Drive wheels 3.00 - 8
Pos Qty. Item No./Pcs. Item Description
- 2 SP1418534 WHEEL 3.00-8" PNEUMATIC; GREY ASSY.
- 2 SP1419258 WHEEL 3.00-8" PNEUMATIC; BLACK ASSY.
- 2 SP1421829 WHEEL 3.00-8" PUNCTURE-PROOF; GREY ASSY.
- 2 SP1421831 WHEEL 3.00-8" PUNCTURE-PROOF; BLACK ASSY.
- 2 SP1421801 WHEEL 3.00-8" TRELLEBORG; GREY ASSY.
- 2 SP1421833 WHEEL 3.00-8" TRELLEBORG PUNCTURE-PROOF;
GREY ASSY.
- 1 SP1423184 MOUNTING SET WHEEL RIM 8" ASSY.
1 1 1418522-0307 RIM RING 8" EXTERNAL
2 4 1419329-0307 RIM RING 8" INTERNAL
3 5 D50120 MACHINE SCREW WITH ALLEN KEY HEAD M6 X 40
- 1 SP1423185 MOUNTING SET TACHO DRIVE ASSY.
4 1 1419340 MAGNET RUBBER
5 1 P30497 CIRCULAR MAGNET 6 X 25
6 1 M12016 INNER TUBE 3.00-8" WITH VALVE TR 87-90/90°
7 1 1415173 TYRE 3.00-8", GREY
7 1 1419257 TYRE 3.00-8", BLACK
- 1 M11968 TYRE 3.00-8" STOLLE; GREY
