Storm³
Service Manual
Page 24 As at:07.03.02
- 1 SP1423186 MOUNTING SET DRIVE UNIT ASSY.
8 1 1418519 BOLT M12 X 100 DIN 7991
19 1 1418520-0003 NUT M12
1 2 M30985 BRAKE BLOCK SET 90 X 18 (ANELLI)
2 1 1421654-0003 COUNTER-HOLDER RH
2 1 1421653-0003 COUNTER-HOLDER LH
- 1 SP1423443 MOUNTING SET WHEEL 3.00-8"
3 1 F00108 HEXAGON NUT M12 X 1.5 SELF-LOCKING
5 4 D60183 COUNTERSUNK SCREW WITH ALLEN KEY HEAD M8 X
20 PB
11 1 1415177 CAP WITH "INVACARE" LOGO
15 1 G00104 WASHER 13 X 24 X 2.5
4 2 D08109 HEX BOLT M6 X 10
6 2 1419287 BOLT M8 X 35 PB DIN 912
7 2 1419288 BOLT M8 X 65 PB DIN 912
9 1 1415192 LINK BLOCK
10 1 1415171 WHEEL HUB FOR BRAKE
- 1 1415172 WHEEL HUB STD.
14 2 1421760 SINTERED METAL BUSH
16 4 G00110 WASHER 6.4 X 12.5 X 1.6
17 2 1423164-0002 WASHER 19 MM WITH RECESS FOR FEATHER KEY
18 1 N23004 FEATHER KEY A 6 X 6 X 40
20 2 F331060 HEXAGONAL SPACER
21 1 1421761 AXLE
22 1 SP1415066 BRAKE ANCHOR PLATE PREASSEMBLED
22 1 SP1415067 BRAKE ANCHOR PLATE PREASSEMBLED
- 1 SP1423441 SPRING SET "HARD"
12 2 1418510 SPRING PLATE
12 4 1418510 SPRING PLATE
13 2 1420010 FITTING AID
13 4 1420010 FITTING AID
23 2 1422834 PRESSURE SPRING "HARD"
- 1 SP1423442 SPRING SET "SOFT"
23 2 1421841 PRESSURE SPRING SOFT
24 1 1421722 DRIVE UNIT 6 KM/H RH
24 1 1421721 DRIVE UNIT 6 KM/H LH
24 1 1421725 DRIVE UNIT 10 KM/H RH
24 1 1421724 DRIVE UNIT 10 KM/H LH
24 1 1421727 DRIVE UNIT 12 KM/H RH
24 1 1421726 DRIVE UNIT 12 KM/H LH
