Invacare Storm 3 - 9.1.1 Replacing castor wheel; front wheel; 9.1.3 Repairing; replacing tyres or inner tube

Storm³
Service Manual
Page 32 As at:07.03.02
- 2 SP1422933 WHEEL 3.00-6" PUNCTURE-PROOF; BLACK ASSY.
- 1 SP1423181 MOUNTING SET WHEEL RIM 6" ASSY.
1 1 1418524-0307 RIM RING 6" EXTERNAL
2 1 1418523-0307 RIM RING 6" INTERNAL
3 5 D50117 MACHINE SCREW WITH ALLEN KEY HEAD M6 X 35
- 1 SP1423182 BEARING SET WHEEL RIM 6" ASSY.
4 2 1417943 DEEP GROOVE BALL BEARING 6004-2SRSR
5 1 1415178-0002 SPACER LINING
6 1 1415175 INNER TUBE 3.00 X 6 90° TR 87
7 1 1418532 TYRE 3.00-6", GREY
7 1 1419226 TYRE 3.00-6", BLACK
-
2 SP1418534 WHEEL 3.00-8" PNEUMATIC; GREY ASSY.
-
2 SP1419258 WHEEL 3.00-8" PNEUMATIC; BLACK ASSY.
-
2 SP1421829 WHEEL 3.00-8" PUNCTURE-PROOF; GREY ASSY.
-
2 SP1421831 WHEEL 3.00-8" PUNCTURE-PROOF; BLACK ASSY.
-
2 SP1421801 WHEEL 3.00-8" TRELLEBORG; GREY ASSY.
-
2 SP1421833 WHEEL 3.00-8" TRELLEBORG PUNCTURE-PROOF;
GREY ASSY.
- 1 M12016 INNER TUBE 3.00-8" WITH VALVE TR 87-90/90°
- 1 1415173 TYRE 3.00-8", GREY
- 1 1419257 TYRE 3.00-8", BLACK
- 1 M11968 TYRE 3.00-8" STOLLE; GREY
- 5 D50120 MACHINE SCREW WITH ALLEN KEY HEAD M6 X 40
- 4 1419329-0307 RIM RING 8" INTERNAL
- 1 1418522-0307 RIM RING 8" EXTERNAL
- 1 1419340 MAGNET RUBBER
- 1 P30497 CIRCULAR MAGNET 6 X 25
Lay the vehicle down on its side on a relatively firm underlay, or place wooden blocks
under the frame so that the castor wheels are not loaded.
