Invacare Storm 3 - 11.4.1 Replacing the equipment rack; 11.4.2 Replacing electronic components

Service Manual
Storm³
As at: 07.03.02 Page 53
2.1 1 P12191 STRIP FUSE 50A
3 1 1415004 LIGHTING PCB (CENTRAL DISTRIBUTOR)
4 2 P11195 CHANGEOVER RELAY WITH BRACKET 24V/10-20A
5 4 D08102 HEX BOLT M5 X 16
6 4 D60177 COUNTERSUNK SCREW WITH ALLEN KEY HEAD M5 X
16
7 2 D08103 HEX BOLT M5 X 20
8 1 1418528 EQUIPMENT RACK
- 1 SP1423191 MOUNTING SET ACS ELECTRONICS HOLDER
9 8 1422052 GETO WELL NUT M5
10 4 1419337 SCREW-IN RIVET
11 1 SP1422053 ACS BUS DISTRIBUTOR ASSY.
11.1 2 D36112 CHEESE HEAD SELF-TAPPING SCREW WITH PHILLIPS
HEAD 4.8 X 16
11.2 1 P10072 ACS BUS T-ADAPTER (DISTRIBUTOR)
12 1 6001825 ACS LIGHTING MODULE 24V STD.
12 1 P10080 ACS LIGHTING MODULE 12V (TÜV).
12 1 P10081 ACS-CLAM (LIGHT-MOTOR MODULE COMBINED)
13 1 GSM63003 ACS BUS CABLE L=300 MM
- 1 1419370 BATTERY CABLE
- 1 1419983 BATTERY CABLE (TÜV VERSION)
- 1 1419390 CLAM WIRING HARNESS ACTUATORS; LIGHT
- 1 1421728 CLAM WIRING HARNESS LIGHT; LIFTER; LEGREST.;
SEAT TILT.
- 1 1421729 CLAM WIRING HARNESS LIGHT; EL. ADJUSTMENT
- 1 1421730 CLAM WIRING HARNESS LIGHT; LEG SUPPORTS;
SEAT TILT.
