StormĀ³
Service Manual
Page 60 As at:07.03.02
- 1 SP1421692 ARMREST RH ASSY. 340 MM
- 1 SP1421694 ARMREST LH ASSY. 340 MM
- 1 SP1421693 ARMREST RH ASSY. 380 MM
- 1 SP1421695 ARMREST LH ASSY. 380 MM
1 1 1421716-9005 ARMREST RH ASSY.
1 1 1421717-9005 ARM SUPPORT LH ASSY.
2 1 D171010A ARMREST PADDING RH; BLACK
2 1 D171009A ARMREST PADDING LH; BLACK
3 1 1421689 "STOP" LABEL
- 1 SP1423221 SIDE PANEL PLATE 340 MM RH ASSY.
- 1 SP1423702 SIDE PANEL PLATE 340 MM LH ASSY.
- 1 SP1423703 SIDE PANEL PLATE 380 MM LH ASSY.
- 1 SP1423701 SIDE PANEL PLATE 380 MM RH ASSY.
4 1 1415027 CLAMPING LEVER M6 X 25
5 1 1422096-9005 SIDE PANEL ADJUSTER RH ASSY. 250-340 MM
5 1 1422095-9005 SIDE PANEL ADJUSTER LH ASSY. 250-340 MM
6 1 L31001 WING NUT M6 X 10
7 2 D10108
COUNTERSUNK SCREW WITH PHILLIPS HEAD M5 X
20
8 2 DG90101 COUNTERSUNK BOLT M5 X 16
9 2 D60111 COUNTERSUNK SCREW WITH ALLEN KEY HEAD M6 X
16
10 2 Z173189.99 NUT M6 SP-14
11 1 1421714-9005 SIDE PANEL MOUNTING
12 2 L01008 SLIDER SL 22
13 2 0572-02152 CIRCULAR WASHER SHAPE B; BLACK
14 1 1420471 SIDE PANEL PLATE
15 1 1422092-0002 CONNECTORS
16 1 1421720-0002 GROOVED SHEET
17 2 5824352 GRUB SCREW M6 X 6 DIN 916
18 a 1 1422089-9005 SIDE PANEL MOUNTING RH
18 a 1 1422097-9005 SIDE PANEL MOUNTING LH
18 b 1 1422115-9005 SIDE PANEL MOUNTING LH SHORT (FOR SB 380 MM)
18 b 1 1422114-9005 SIDE PANEL MOUNTING RH SHORT (FOR SB 380 MM)
To Next Page
