Service Manual
StormĀ³
As at: 07.03.02 Page 67
1 1 1420475 GEARED MOTOR GMPG
2 1 1420482 REFLECTOR
3 1 1419992-9005 BACKREST ATTACHMENT 430 MM
3 1 1422112-9005 BACKREST ATTACHMENT 480 MM
4 1 1422887 LIMIT SWITCH
5 1 1420497-0003 MICROSWITCH PLATE
6 2 5729071 FIBREGLASS WASHER
7 2 D36111
CHEESE HEAD SELF-TAPPING SCREW WITH PHILLIPS
HEAD 2.9 X 16
8 1 1421696 REFLECTOR PERFORATED; YELLOW
9 2 5729029 RETAINING RING
- 1 SP1423212 ANGULAR SENSOR ASSY.
10 1 ANGULAR SENSOR
11 1 1420999-0003 ANGULAR SENSOR PLATE
12 1 D30110 MACHINE BOLT WITH PHILLIPS HEAD M4 X 16
13 6 F60107 HEXAGON CAP NUT M6 SELF-LOCKING
14 2 F20104 HEXAGON NUT M6 SELF-LOCKING
15 4 F00002 HEXAGON NUT M8 SELF-LOCKING
16 4 D60111
COUNTERSUNK SCREW WITH ALLEN KEY HEAD M6 X
16
17 8 5824259 BOLT M8 X 20
18 1 1420998 MOTOR CAP
19 1 1420490 CONNECTING TUBE 430 MM
19 1 1420491 CONNECTING TUBE 480 MM
20 1 1420477-9005 FITTING ATTACHMENT LH
20 1 G00103 WASHER 4.3 X 9 X 0.8
21 2 G00115 WASHER 6.4 X 12.5 X 1.6
22 4 G00110 WASHER 6.4 X 12.5 X 1.6
23 4 G00107 WASHER 8.4 X 17 X 1.6
25 1 1420487-0002 MOTOR SHAFT
26 1 1420488-0002 ARMATURE SHAFT
- 1 SP1423215 SEAT FITTINGS ASSY. (PAIR)
27 2 1419980 SEAT COVER
28 1 1421708-9005 FITTING ATTACHMENT RH
