iPECS UCP
Hardware Description and Installation Manual Issue 1.3
103
or, for 1000 Base-T Cat 5e UTP cable. The maximum wire length between the IP Phone
and the Ethernet switch port is 100 meters or 328 feet.
2. Use the RJ45 terminated cable provided with the phone to connect the IP Phone LAN
port to the Wall outlet.
3. Connect the PC port to a PC LAN port using a CAT 5 or 5e cable terminated on each
end with an RJ45 connector.
4. If not using a PoE switch port, connect the DC connector of an AC Adaptor-K to the DC
input on the bottom of the IP Phone and plug the AC plug of the AC adaptor in to a 100-
240 VAC outlet.
Once the LIP phone powers up, it will attempt to register with the iPECS UCP. From default, the
LIP phone should complete the registration successfully. If not, the phone will display the “No
Response” message shown below.
NO RESPONSE FROM MFIM [L]
SET[*] – RETRY[#]
This indicates the LIP phone needs to be configured for the local network environment. To
configure the phone, perform the following steps.
1. Press ‘*’ to set the network configuration.
2. Enter the password, 147*.
3. Use the Volume Up/Down buttons to scroll through the menu shown below.
4. Enter appropriate values for the local network.
5. When complete, press the Speaker button.
6. Press ‘*’ to exit and restart the LIP Phone.
Registration mode, use ‘#’ to set Remote mode
PHONE IP ADDRESS (DOT:*) Use the dial pad to enter the fixed IP address, use DHCP
for dynamic addressing
PHONE NET MASK(DOT:*) Use the dial pad to enter the Subnet mask if using fixed IP
addressing
ROUTER IP ADDRESS(DOT:*)
