6.2 UCP server Module Installation
There are several models of the UCPs, which are all installed in the same manner. In this section,
the reference to UCPs encompasses the various models of UCPs. The UCPs may be installed
anywhere except for slot 10 of the cabinet, or may be installed anywhere in the Desk Mount
Holder.
All UCPs contain a long life Lithium battery, which protects the real-time clock in the event of a
power failure. Minimum battery life is 10 years and the battery is not field-replaceable.
LEDs
In addition to the Power and LAN LEDs, UCPs have ten LEDs for status and diagnostic
information as in Table 6.2-1.
Table 6.2-1 UCP100/600/2400 Status LED Functions
LED
LED STATUS FUNCTION - ON -
S1 Serial/TCP debug active
S2 Call Processing active
S3 Active data communication with Modules and IP Phones
S4
LCD control active
S5 CPU active (100ms flashing)
BGM BGM or internal MOH active
PAGE Ext. Page1 or Ext. Page2 in use
S6 Reserved
S7 Redundancy active (flashing during DB download)
S8 MISC Active (Flashing)
Mode Switch & Settings
UCP modules have a four (4) position DIP-switch identified as the “MODE” switch. The function of
each switch position is given in Table 6.2-2 below.
Table 6.2-2 UCP Mode Switch Functions
SWITCH
FUNCTION
ON
OFF
1
Database write protect Protect, cannot modify Unprotect, can modify
2
Reserved - -
3
Registration
Allow registration
(Auto register new device)
Registration denied
(Manual register only)
4
Initialization Initialize DB on Reset Read stored DB on Reset
To enter data in the system’s database, the Write Protect switch must be in the OFF position. In
