iPECS UCP
Hardware Description and Installation Manual Issue 1.3
11
2.4.3 Environment specification
Table 2.4.3-1 Environmental Specifications
ITEM
TEMPERATURE
Operation Temperature
0~40
0
C 32~104
0
F
Optimum Operation Temperature
20~26
0
C 68~78
0
F
Storage Temperature
-20~60
0
C -4~140
0
F
Relative Humidity
0~80% non-condensing
2.4.4 Electrical specification
2.4.4.1 System Electrical specification
Table 2.4.4.1-1 System Electrical Specifications
ITEM
SPECIFICATIONS
Module AC/DC Adapter
AC Voltage Input
100-240 VAC, +/-10% @ 50/60 Hz
AC Current Input
1.0 amps
DC Output
48 VDC at 0.8 amps
Keyset AC/DC Adapter
AC Voltage Input
100-240 VAC, +/-10% @ 50/60 Hz
AC Current Input
0.2 amps
DC Output
48 VDC at 0.3 amps
PSU
AC Voltage Input
100-240 VAC, +/-10% @ 50/60 Hz
Fuse
T6.3, AC250V
DC Output
48VDC, 5.3 amps
5VDC at 1 amps
SLTM32 PSU
AC Voltage Input
187~265 VAC @ 47~63 Hz
Fuse
T1, AC250V
DC Output
30VDC at 1.2 amps
5VDC at 2.5 amps
5VDC at 0.1 amps
External Relay Contact
2 amp @ 30 VDC
Music Source Input
0 dBm @ 600 ohm
External Paging Port
0 dBm @ 600 ohm
LAN Power Feed
0.3 amps max
