iPECS UCP
Hardware Description and Installation Manual Issue 1.3
83
6.6 BRIM2 Installation
The BRIM2 and BRIM4 may be installed anywhere except for slot 10 of the cabinet, or may be
installed anywhere in the Desk Mount Holder. The BRIM2 and BRIM4 provide a gateway
between ISDN Basic Rate Interface (BRI) lines and other iPECS appliances. The BRIM2 can
support two (2) BRI lines as a “T” interface and the BRIM4 can support four (4) BRI lines.
LEDs
In addition to the Power and LAN LEDs, there are four or eight LEDs, two for each BRI circuit,
which provide the status information as described in Table 6.6-1.
Table 6.6-1 BRIM2 Status LED Function
LED
ON
OFF
ACT
In Use Idle
ERR
Line Error Normal
Wiring Connectors
Before wiring any of the Modules, first connect the “ ” screw on the back of the Module to a
known ground, refer to 6.1.4. If installed in a cabinet assure the cabinet is grounded.
On the front of the BRIM2 and BRIM4 is the RJ–45 type “LAN” connector. This connector should
be wired to the appropriate LAN points as discussed in 6.1.6 and 6.1.7.
 Wire “LAN” to a 10/100 Base-T switch, an ES8G/ES8GP can be used to connect to the
LAN.
 Tag or number wiring for maintenance.
On the rear are two (2) or four (4) RJ-45 connectors terminated to the BRI Line interface circuits.
These connectors should be wired to the telephone company termination point (“T” Mode). The
connector pin assignments for the RJ-45 type jacks on the BRIM2 and BRIM4 are shown in
Figure 6.6-1 and Figure 6.6-2, respectively.
 Wire each RJ-45 to a BRI line at the ISDN termination point/MDF.
 Tag or number wiring for maintenance.
AC/DC Adapter
If a PSU is not employed, assure the AC/DC Adapter is plugged into a live AC outlet and the
Module Power jack.
