iPECS UCP - Maximum Station Wiring; Analog CO Loop Specification

iPECS UCP
Hardware Description and Installation Manual Issue 1.3
14
Table 2.4.4.2-4 LIP 9000 Phone Power Requirements
Model
Current
(mA)
IEEE 802.3af
Class
LIP-9040
98 2
LIP-9030
98 2
LIP-9020
96 2
LIP-9010
84 1
LIP-9002
39 1
LIP-9040 with 9024ButtonKit
112 2
LIP-9030 with 9024ButtonKit
112 2
LIP-9020 with 9024ButtonKit
106 2
2.4.5 Maximum Station Wiring
Table 2.4.5-1 Maximum Station Wiring Distance
ITEM
DISTANCE (M/KFt)
22 AWG
24 AWG
LIP Phone to switch port
100/0.328 100/0.328
SIP or H.323 VoIP phone
100/0.328 100/0.328
Digital Terminal to DTIM
500/1.64 300/1
Single Line Telephone to SLTM
6,000/20 4,000/13
2.4.6 Analog CO Loop specification
Table 2.4.6-1 CO Loop Specifications
ITEM
SPECIFICATION
Ring Detect Sensitivity
40 Vrms @ 16~30 Hz
30 Vrms @ 30~37 Hz
DTMF Dialing
Frequency Deviation
Less than +/-1.8%
Signal Rise Time
Max. 5ms
Tone Duration, ON time
Min. 50ms
Inter-digit Time
Min. 30ms
Pulse Dialing
Pulse Rate
10 pps
Break/Make Ratio
60/40% or 67/33%
NOTE
1. Ring sensitivity on analog CO Lines will vary from one regulatory region to another.
