iPECS UCP - Page 21

iPECS UCP
Hardware Description and Installation Manual Issue 1.3
13
Table 2.4.4.2-2 LIP 8000E Phone Power Requirements
Model
Current
(mA)
IEEE 802.3af
Class
LIP-9070
250 3
LIP-8050E
125 3
LIP-8040E
89 2
LIP-8024E
87 2
LIP-8012E
84 2
LIP-8008E
40 2
LIP-8002E
39 1
LIP-8050E with 1 LSS
134 3
LIP-8050E with 2 LSS
143 3
LIP-8040E with 1 LSS
98 2
LIP-8040E with 2 LSS
107 2
LIP-8024E with 1 LSS
96 2
LIP-8024E with 2 LSS
105 2
LIP-8012E with 1 LSS
93 2
LIP-8012E with 2 LSS
102 2
Table 2.4.4.2-3 LIP 8000 Phone Power Requirements
Model
Current
(mA)
IEEE 802.3af
Class
LIP-8050
127 3
LIP-8040
105 2
LIP-8024
103 2
LIP-8012
96 2
LIP-8008
90 2
LIP-8002
91 1
LIP-8050 with 1 LSS
136 3
LIP-8050 with 2 LSS
145 3
LIP-8040 with 1 LSS
114 2
LIP-8040 with 2 LSS
123 2
LIP-8024 with 1 LSS
112 2
LIP-8024 with 2 LSS
121 2
LIP-8012 with 1 LSS
105 2
LIP-8012 with 2 LSS
114 2
NOTE
1. LIP-8012DSS and LIP-8012LSS Serial Consoles are powered from LIP-8050E,
LIP-8040E, LIP-8024E, or LIP-8012E Phones. The chart shows the power
consumption when an LIP-8012LSS is attached. These power consumption
values should also be used when connecting an LIP-8012DSS.
