2.4 System Specifications
2.4.1 System Capacity
Table 2.4.1-1 System Capacities
ITEM
UCP100
UCP600
UCP2400
Remark
Main Cabinet
10 Slots 1 slot used by the PSU
System channels, basic
maximum
50 100 600
199 600 2400 w/License
Stations
199 600 2400
Total stations and Lines
cannot exceed the
available System channels
CO/IP Lines (external network
channels incl. VoIP)
199 600 998
UCS Standard Clients
Registrations
Simultaneous
UCS Premium Clients
Registrations
100
100
199
200
200
600
400
400
2400
Server Redundancy
No Yes Yes
Supports local and remote
redundancy
Cabinet Power Redundancy
Yes
Integrated Telephony ports
*1
None None
Two FXS ports are
equipped as standard in
the UCP100 module; an
optional CO/BRI line unit
may be equipped or
installed.
standard
2 FXS (SLT)
optional
4 CO, or 2 BRI
or 4 BRI Lines
WTIM4/8 modules (Max.)
132
Max DECT phones
100 255 255
VoIP Switch channels,
*2&3
Built-in basic
Built-in maximum
System Maximum
8
16
100
8
24
600
0
0
998
w/License
w/VOIM and VCIM
VoIP DSP channels,
Built-in max
6 6 0
VoIP DSP channels can be
assigned to the MCIU, 2
VoIP = 4 Conf channels.
For UCP100 see Note 1.
Multi-party Conference Unit
(MCIU) channels
6/10/14/18 6/18 0
Maximum MCIMs
30
Max SIP channels
100 600 1200
VSF
*4
8-Ch./4 Hrs. 8-Ch./6Hrs. NA
14 Hours 16 Hours NA w/License
UVM capacity, basic
maximum
8 Channels at 50 hours
16 Channels at 200 hours w/License
UVM per system
30
Attendants
50
Serial Port (RS-232C)
1
