6.10 SLTM4 & SLTM8 Installation
The SLTM4 and SLTM8 may be installed anywhere except for slot 10 of the cabinet, or may be
installed anywhere in the Desk Mount Holder. The SLTM4 provides a gateway between four (4)
standard Single Line Telephone devices and other iPECS appliance and the SLTM8 provides
eight (8).
LEDs
In addition to the Power and LAN LEDs, the SLTM4 has four (4) status LEDs, one (1) for each
SLT port. The LEDs indicate the status of the associated SLT port in-use (LED ON), ringing (LED
flashing) or idle (LED OFF).
In addition to the Power and LAN LEDs, the SLTM8 has eight (8) status LEDs, one (1) for each
SLT port 1~8. The LEDs indicate the status of the associated SLT port in-use (LED ON), ringing
(LED flashing) or idle (LED OFF).
Wiring Connectors
Before wiring any of the Modules, first connect the “ ” screw on the back of the Module to a
known ground, refer to 6.1.4. If installed in a cabinet assure the cabinet is grounded.
On the front of the SLTM4 and SLTM8 is the RJ 45 type “LAN” connector. This connector should
be wired to the appropriate LAN points as discussed in 6.1.6 and 6.1.7.
 Wire “LAN” to a 10/100 Base-T switch, an ES8G/ES8GP can be used to connect to the
LAN.
 Tag or number wiring for maintenance.
On the rear are four (4) or eight (8) RJ-45 connectors terminated as described in 6.1.5, which
should be wired to the SLT termination points.
 Wire each RJ-45 to an SLT device/MDF.
 Tag or number wiring for maintenance.
AC/DC Adapter
If a PSU is not employed, assure the AC/DC Adapter is plugged into a live AC outlet and the
Module Power jack.
