iPECS UCP
Hardware Description and Installation Manual Issue 1.3
97
6.16 WTIM4/8 Installation
A WTIM4 or WTIM8 may be installed anywhere except for slot 10 of the cabinet, or may be
installed anywhere in the Desk Mount Holder. The WTIM4/8 is connected to the GDC-600BE
System DECT Base Station, which provides the RF link between DECT handsets such as GDC-
450H/480H/500H and other iPECS appliances.
The WTIM4 can provide up to four (4) GDC-600BE interfaces. The WTIM8 can provide up to
eight (8) GDC-600BE interfaces. Detailed instructions on configuration and installation of WTIMs
and Base Stations (GDC-600BE) are provided in the System DECT Installation Manual. The
following information is provided for reference only.
LEDs
In addition to the Power and LAN LEDs, the WTIM4/8 has eight (8) status LEDs. The definition of
LEDs is shown in Table 6.16-1 below.
Table 6.16-1 WTIM4/8 Status LED Functions
LED
LED FUNCTION
CP1 Main CPU is normal, LED flashes.
CP2 Sub CPU is normal, LED flashes.
WBUS WTIM communicating with another WTIM, LED flashes.
USE
Two or more DECT channel(s) in use, LED ON.
LINK WTIM connected to UCP via LAN, LED ON.
HBUS WTIM communicating with UCP, LED flashes.
E1 WTIM communicating with Base Station (GDC-400B), LED flashes.
M/S Main WTIM, LED is turned ON.
Sub-WTIM, LED is turned OFF.
MODE Switch & Settings
Each WTIM has a four (4) position DIP-switch. The function of each switch position is given in
Table 6.16-2 below.
Table 6.16-2 WTIM4/8 Mode Switch Functions
SWITCH
FUNCTION
ON
OFF
DEFAULT
1 Reserved TBR6 test mode Normal OFF
2 Echo-canceller control
when CRC error at
600BE
Enable
(Enable mute
Function)
Disable
(Disable mute
Function)
ON
3 Serial selection Sub CPU Serial mode Main CPU Serial mode
ON
4 S/W debugging All base reset One base reset OFF
