iPECS UCP
Hardware Description and Installation Manual Issue 1.3
37
3.1.15 AD/DC adapter –G
An optional AC/DC adapter is available to power a
module when the PSU is not employed. The adapter is
supplied with a two (2) meter, six (6) foot, AC cord
terminated with the nationally relevant AC blade type.
The adapter supports AC input power systems with
rated voltage range of 100-240 VAC @ 50/60 Hz. The
adapter provides 48 VDC, 0.8 amps. The DC output
connector is cabled to the adapter with a two (2) meter,
six (6) foot, cable.
Figure 3.1.15-1 AD/DC adapter –G
