6.8 DTIM8 Installation
The DTIM8 may be installed anywhere except for slot 10 of the cabinet, or may be installed
anywhere in the Desk Mount Holder. The DTIM8 provides a gateway between Ericsson-LG
Enterprise’s Digital terminals (LKD and LDP models) and other iPECS appliances. The DTIM8
can support eight (8) Digital terminals.
LEDs
In addition to the Power and LAN LEDs, the DTIM8 has eight (8) status LEDs. These LEDs
indicate that the individual Digital terminals are busy (LED ON), idle (LED OFF) or ringing (LED
flashing).
Wiring Connectors
Before wiring any of the Modules, connect the “ ” screw on the back of the Module to a known
protective earth ground, refer to 6.1.4. If installed in a cabinet assure the cabinet is grounded.
On the front of the DTIM8 is the RJ-45 type “LAN” connector. This connector should be wired to
the appropriate LAN points as discussed in 6.1.6 and 6.1.7.
 Wire “LAN” to a 10/100 Base-T switch, an ES8G/ES8GP can be used to connect to the
LAN.
 Tag or number wiring for maintenance.
On the rear are eight (8) RJ-45 connectors terminated as described in 6.1.5. These should be
wired to the digital terminal termination point.
 Wire the RJ-45 connectors to a Digital terminal termination point/MDF.
 Tag or number wiring for maintenance.
AC/DC Adapter
If a PSU is not employed, assure the AC/DC Adapter is plugged into a live AC outlet and the
Module Power jack.
