2.3 Hardware Components Chart
Table 2.3-1 provides a description of the hardware components that make-up iPECS UCP. All of
the Modules are connected over standard Ethernet LANs. Multiple options permit module
installation in a cabinet, bookshelf mount, or individual mounting.
Table 2.3-1 iPECS Modules
ITEM
DESCRIPTION
1
UCP100 Unified Communications Platform Server 100, Basic 50, Up to 199 ports
UCP600 Unified Communications Platform Server 600, Basic 100, Up to 600 ports
UCP2400
Unified Communications Platform Server 2400, Basic 600, Up to 2400 ports
UCP-COIU4 4 ports Central Office Interface Unit daughter board for UCP100
UCP-BRIU2
2-port Basic Rate Interface Unit daughter board for UCP100
UCP-BRIU4 4-port Basic Rate Interface Unit daughter board for UCP100
2
VOIM8
Voice Over IP Gateway Module, 8 channels
3
VOIM24 Voice Over IP Gateway Module, 24 channels
4
VCIM
VoIP and Conference Interface Gateway Module, Basic 64 DSP channels,
Up to 128 DSP channels with software license.
(Default 31 VoIP or 62 Conference, Maximum 63 VoIP or 126 Conference)
5
LGCM4 Loop Start CO gateway Module, 4 ports
6
LGCM8 Loop Start CO gateway Module, 8 ports
CMU1216 4-channel Call Metering Unit for LGCM, 12 or 16KHz, Polarity Reversal
CMU50PR 4-channel Call Metering Unit for LGCM, 50Hz, Polarity Reversal
7
BRIM2 BRI gateway Module, 2 port ISDN “T” Interface (2B+D)
8
BRIM4
BRI gateway Module, 4 port ISDN “T” Interface (2B+D)
9
PRIM PRI gateway Module, 1 port, 24 (23+1) or 32 (30+2) channels
10
DTIM8
Digital Terminal Interface gateway Module, 8 ports
11
DTIM24 Digital Terminal Interface gateway Module, 24 ports
12
SLTM4
Single Line Telephone gateway Module, 4 ports
13
SLTM8 Single Line Telephone gateway Module, 8 ports
14
SLTM32 Single Line Telephone gateway Module, 32 ports
15
UVM Unified Voice Mail Interface Module, Up to 16 Channels/200 Hours
16
MCIM Multi-Media Conference Module (up to 32-party voice)
17
WTIM4 Wireless Terminal Interface gateway Module, 4 ports
18
WTIM8 Wireless Terminal Interface gateway Module, 8 ports
19
ES8G 8 +1 Port switch, 10/100/1000 Base-T Ethernet interface
20
ES8GP
PoE Switch, 8 +1 Ports, 10/100/1000 Base-T Ethernet interface
21
AC/DC Adapter –G- AC/DC Adapter for standard iPECS gateways & modules, (48VDC, 0.8A)
22
DHLD
Desk mount Holder for module
23
DHE Desk mount Holder Extender, one (1) required for each Module
24
WHLD
Wall mount Holder for module
25
MCKTE Main Cabinet Kit Enhanced
26
WBRKE Wall mount Bracket Kit for Enhanced Main Cabinet
27
1U-RMB 1U Rack mount Bracket for gateway Modules
