6.3 VOIM8/24 Installation
The VOIM8/24 may be installed anywhere except for slot 10 of the cabinet, or may be installed
anywhere in the Desk Mount Holder. The VOIM8/24 is used to provide packet relay for remote
devices to communicate with the host and translation between the iPECS proprietary protocols
and other standard protocols (H323, SIP).
LEDs
The VOIM8 and VOIM24 have five (5) LEDs for status and diagnostic information as in Table
6.3-1.
Table 6.3-1 VOIM8 & VOIM24 Status LED Functions
LED
LED FUNCTION
S1
Trace Task active
S2
VOIM Task active
CALL
VoIP call active
S3
Registered to UCP
DSP
Transcoding in use
Wiring Connectors
Before wiring any of the Modules, first connect the “ ” screw on the back of the Module to a
known ground, refer to 6.1.4. If installed in a cabinet assure the cabinet is grounded.
A “WAN” RJ45 type connector is located on the front of the VOIM8/24. This connector should be
wired to the appropriate LAN points as discussed in 6.1.6 and 6.1.7. In addition, the VOIM8/24
includes an unused “LAN” RJ-45 type connector. Currently this LAN port is not used and no
connection should be made to this port.
 Wire the “WAN” connector to a 10/100 Base-T switch, an ES8G/ES8GP can be used to
connect to the LAN.
 Tag or number wiring for maintenance.
AC/DC Adapter
If a PSU is not employed, assure the AC/DC Adapter is plugged into a live AC outlet and the
Module Power jack.
