ManagerIQEasy_UM_9752103002_GB_V3_1 18

- Place the housing behind the machine panel and secure it with the 4 tap bolts and washers (1).

Make sure that the wires are not squeezed between the housing and the machine panel.

- Screw the four snap connectors into the housing through the machine panel.
