ITW SIMCO ION Manager IQ Easy User Manual

ManagerIQEasy_UM_9752103002_GB_V3_1 53
Toggle RS485 AB
Off
The signals on the Device communication port
are not switched.
On
The signals on the Device communication port
are switched. Enable this parameter if older
Performax IQ and/or Sensors are used in the
system. The parameter can also be switched on if
a mistake is made during the wiring, as a result of
which Devices are not detected by the HMI.
Autorun
Yes
For a Backplane and Extension IQ Easy, this
parameter will always be set to Yes. The Backplane
and Extension IQ Easy units will always be started.
Firmware version
Identification of the current firmware version of
the Backplane or Extension IQ Easy.
Port5 Mode
Serial
The Device port is set and suitable for
communicating with IQ Easy Devices.
Analog I/O
The Device port is set to communicate with Non-
IQ Easy Devices.
Port6 Mode
Serial
The Device port is set and suitable for
communicating with IQ Easy Devices.
Analog I/O
The Device port is set to communicate with Non-
IQ Easy Devices.
OE/OC Mode
OE-Mode
The digital Remote I/O outputs (“All system
functions OK”, “Global Alarm” and “Global
Warning”) are used as Open Emitter. See also
Section 5.4.4.1.
OC-Mode
The digital Remote I/O outputs (“All system
functions OK”, “Global Alarm” and “Global
Warning”) are used as Open Collector. See also
Article 5.4.4.1.
SysOk output active
low
No
The “All system functions OK” on the Remote I/O
output is used as an “Active High” signal. See
also Article 5.4.4.1.
Yes
The “All system functions OK” on the Remote I/O
output is used as an “Active Low” signal. See also
Article 5.4.4.1.
Alarm output active low
No
The “Global Alarm” on the Remote I/O output is
used as “Active High” signal. See also Article
5.4.4.1.
Yes
The “Global Alarm” on the Remote I/O output is
used as “Active Low” signal. See also Article
5.4.4.1.
Warning output
active low
No
The “Global Warning” on the Remote I/O output
is used as “Active High” signal. See also Article
5.4.4.1.
Yes
The “Global Warning” on the Remote I/O output
is used as “Active Low” signal. See also Article
5.4.4.1.
Remote IN
Off
Feedback from the “Remote On/Off” signal from
the Remote I/O connector. Can be used for
testing purposes. See also Article 5.4.4.2.
On
Fieldbus IN (*)
Off
Feedback from the “Remote On/Off” control of
the Fieldbus protocol. Can be used for testing
purposes.
On
(*): This parameter is only available in (Fieldbus) versions of the Backplane.
