SECTION 1. SPECIFICATIONS
1.1 SPECIFICATIONS
Table 1-1. Operating Specifications
Description 1930ES 2030ES 2630ES 2646ES 3246ES
Maximum Stowed Travel Grade
(Gradeability)
25% 25% 25% 25% 25%
Maximum Stowed Travel Grade
(Sideslope)
5° 5° 5° 5° 5°
Maximum Platform Height
18.75 ft.
5.7 m
20 ft.
6 m
25.8 ft.
7.9 m
26 ft.
7.9 m
32 ft.
9.8 m
Maximum Tire Load:
AN SI
CE
1365 lb (620 kg)
1540 lb (699 kg)
1660 (755)
1835 lb (832 kg)
1835 lb (832 kg)
1835 lb (832 kg)
2070 lb (939 kg)
2320 lb (1052 kg)
2070 lb (939 kg)
2320 lb (1052 kg)
Ground Bearing Pressure (ANSI)
109 psi
(7.7 kg/cm
2
)
81 psi
(5.7 kg/cm
2
)
90 psi
(6.3 kg/cm
2
)
87 psi
(6.1 kg/cm
2
)
87 psi
(6.1 kg/cm
2
)
Ground Bearing Pressure (CE)
8.7 kg/cm
2
(123 psi)
6.3 kg/cm
2
(90 psi)
6.3 kg/cm
2
(90 psi)
6.9 kg/cm
2
(98 psi)
6.9 kg/cm
2
(98 psi)
Maximum Drive Speed
3 mph
(4.8 kmh)
3 mph
(4.8 kmh)
2.75 mph
(4.4 kmh)
2.5 mph
(4 kmh)
2.5 mph
(4 kmh)
Maximum Wind Speed
(Depending on model, market, and
indoor/outdoor selection)
28 mph
(12.5 m/s)
Maximum Horizontal Manual Side Force:
ANSI/CSA
ANSI/CSA (Indoor)
ANSI/CSA (Outdoor)
ANSI/CSA (Zone A)
ANSI/CSA (Zone B)
CE (I ndo or)
CE (O utd oor)
AUS (In doo r)
AUS (Indoor Zone A)
AUS (Indoor Zone B)
AUS (Outdoor)
AUS (Outdoor Zone A)
AUS (Outdoor Zone B)
100 lb force (445 N)
N/A
N/A
N/A
N/A
90 lb force (400 N)
45 lb force (200 N)
90 lb force (400 N)
N/A
N/A
45 lb force (200 N)
N/A
N/A
120 lb force (533 N)
N/A
N/A
N/A
N/A
90 lb force (400 N)
45 lb force (200 N)
90 lb force (400 N)
N/A
N/A
45 lb force (200 N)
N/A
N/A
N/A
N/A
N/A
120 lb force (533 N)
100 lb force (445 N)
90 lb force (400 N)
N/A
N/A
90 lb force (400 N)
90 lb force (400 N)
N/A
N/A
N/A
150 lb force (667 N)
N/A
N/A
N/A
N/A
90 lb force (400 N)
90 lb force (400 N)
90 lb force (400 N)
N/A
N/A
90 lb force (400 N)
N/A
N/A
N/A
N/A
N/A
150 lb force (667 N)
105 lb force (467 N)
90 lb force (400 N)
45 lb force (200 N)
N/A
90 lb force (400 N)
90 lb force (400 N)
N/A
N/A
45 lb force (200 N)
Maximum Hydraulic Pressure 1800psi 1800 psi
1700 psi (single)
1850 psi (dual)
2000 psi 2000 psi
Inside Steer Angle 90° 90° 90° 90° 90°
Outside Steer Angle 69° 73° 73° 67° 67°
Electrical System Voltage (DC) 24V 24V 24V 24V 24V
Approximate Gross Machine Weight -
ANSI/CSA
2685 lbs 3830 lbs 4815 lbs 4945 lbs 4945 lbs
Approximate Gross Machine Weight -
CE/Australia
1495 kg 2063.8 kg 2197.7 kg 2705.7 kg 2871.2 kg
Ground Clearance with pot hole
protection system up
3.5 in (8.9 cm)
Ground Clearance with pot hole
protection system down
1 in (2.5 cm) 0.75 in (1.9 cm)
