JLG 1930ES - Electrical Components - Sheet 2 of 2

SECTION 7 - GENERAL ELECTRICAL INFORMATION & SCHEMATICS
3121166 – JLG Lift – 7-33
Electrical Components - Sheet 2 of 2
Figure 7-31. Electrical Components - Sheet 2 of 2
NOTE: (USA Built Machines Prior to S/N 0200135154) (Belgium Built Machines Prior to S/N 1200004293)
*
NOTE: THIS CONNECTION USED ONLY WHEN FOOTSWITCH OR BATTERY CHARGER INTERLOCK OPTIONS ARE REQUIRED.
POTHOLE
PROTECTION
SWITCHES
ALARM
INVERTER
INVERTER
POWER
SWITCH
BEACON LIGHT
BATTERIES
CONTACTOR
RELAY
POWER
BATTERY
CHARGER
PUMP/MOTOR/RESERVOIR
*
