JLG 1930ES - Platform Board J3

SECTION 7 - GENERAL ELECTRICAL INFORMATION & SCHEMATICS
3121166 – JLG Lift – 7-15
Table 7-5. Platform Board J3
Pin Function Type Range (V)
1 Ground Power Output 0
2 Swtich Shield (Grounded) Output 0
3 Not Used -- --
4 Not Used -- --
5 Not Used -- --
6 Not Used -- --
7 Indoor/Outdoor Select Switch (Active Low) Input Vbatt
Table 7-6. Platform Board J4
Pin Function Type Range (V)
1 Ground Power Output 0
2 Switch Shield (Ground) Power Output 0
3 Not Used -- --
4 Not Used -- --
5 Not Used -- --
6 Not Used -- --
7 Horn Switch (Active Low) Input Vbatt
Table 7-7. Power Module (1600346 Power Module ONLY)
Pin Function Type Range (V)
1 Ignition Power Input Vbatt
2 Not Used -- --
3 Not Used -- --
4 Not Used -- --
5 Not Used -- --
6 Not Used -- --
7 Not Used -- --
8 Line Contactor High Side Power Output Vbatt
9 Not Used -- --
10 CAN Bus High Input/Output Comm
11 CAN Bus Low Input/Output Comm
12 Not Used -- --
