SECTION 5 - JLG CONTROL SYSTEM
5-28 – JLG Lift– 3121166
5.11 MACHINE CONFIGURATION PROGRAMMING INFORMATION - ZAPI - 1001092456
NOTE: When configuring an ES scissors machine, the machine configuration must be completed before any personality set-
tings can be changed. Changing the personality settings first and then changing the model number of the machine con-
figuration will cause the personality settings to return to default.
Shaded entries are not available for the selected Market.
Table 5-6. Machine Configuration Programming Information
(Machines with ZAPI - 1001092456 Power Module Only)
Configuration
Digit
Setting Description
* Market Default Setting
012345
1
(Model #)
1
2
3
4
5
1930ES
2030ES
2630ES
2646ES
3246ES
(Set to your applicable ES Model
1 through 5)
2
(Market *)
0
1
2
3
4
5
ANSI USA
ANSI EXPORT
CSA
CE
AUSTRALIA
JAPAN
0 - (ANSI USA)
(Set to your applicable market)
3
(Tilt Cutout)
0
1
NO - Drive and lift up not prevented while tilted (Ground and Platform Mode).
YES - Drive and lift up prevented while tilted (Ground and Platform Mode).
1 1 101 1
4
(Drive Cutout)
0
1
NO - Drive and lift up not prevented while elevated.
YES - Drive and lift up prevented while elevated.
0
5
(Charger Interlock)
0
1
DRIVE ONLY - Drive motion prevented while vehicle is charging.
DRIVE AND LIFT UP - Drive and lift up motions are prevented while vehicle is charg-
ing. Required for CE.
000000
6
(Ground Alarm)
0
1
2
NOT INSTALLED - Vehicle alarm will function for Arm Guard (if enabled), Overload (if
LSS enabled, and as a horn.
DESCENT - Vehicle alarm will function for Arm Guard (if enabled), Overload (if LSS
enabled, as a horn and during Lift Down motion.
MOTION - Vehicle alarm will function for Arm Guard (if enabled), Overload (if LSS
enabled, as a horn and during Drive and Lift motion.
2220
22
7
(Load)
0
1
2
NOT INSTALLED - Load Sensing System (LSS) is not fitted to the vehicle.
CUTOUT PLT - Load Sensing System (LSS) is fitted and Platform Controls are pre-
vented in the event of an Overload. Ground Controls remain functional. This is the
default setting for CE machines.
CUTOUT ALL - Load Sensing System (LSS) is fitted. Platform and GRound Controls
are prevented in the event of an overload.
010101
8
(Battery)
0
1
FLOODED - Batteries are conventional lead-acid type.
AGM - Batteries are absorbed glass mat type.
0
9
(Footswitch)
0
1
NO - Vehicle is not fitted with a footswitch
YES - Vehicle is fitted with a footswitch
0 0 0 0 01
1001115626-B
