SECTION 7 - GENERAL ELECTRICAL INFORMATION & SCHEMATICS
7-36 – JLG Lift – 3121166
Electrical Components - Sheet 1 of 2
Figure 7-34. Electrical Components - Sheet 1 of 2
NOTE: 1930ES: USA Built Machines S/N 0200151266 to Present, Belgium Built Machines SN 1200007882 to Present;
2030ES/2630ES: USA Built Machines S/N 0200152528 to Present, Belgium Built Machines S/N 1200008481 to
Present; 2646ES/3246ES: USA Built Machines S/N 0200151606 to Present, Belgium Built Machines S/N
11200008265 to Present
LIFT
CYLINDER
VALVE
BLOCK
PLATFORM
CONSOLE
BOX
GROUND
CONTROL
BOX
ROTARY ANGLE
SENSOR
BRAKE
DISCONNECT
SWITCH
OR
BRAKE
RELEASE
SWITCH
PLATFORM
RECEPTACLE
DRIVE
MOTORS
DIAGNOSTIC
ANALYZER
