JLG 1930ES - Cylinder Specifications; Major Component Weights; Critical Stability Weights

SECTION 1 - SPECIFICATIONS
1-8 – JLG Lift – 3121166
1.5 CYLINDER SPECIFICATIONS
1.6 MAJOR COMPONENT WEIGHTS
1.7 CRITICAL STABILITY WEIGHTS
DO NOT REPLACE ITEMS CRITICAL TO STABILITY, SUCH AS
BATTERIES OR SOLID TIRES, WITH ITEMS OF DIFFERENT-
WEIGHT OR SPECIFICATION. DO NOT MODIFY UNIT IN ANY WAY
TO AFFECT STABILITY.
Table 1-15. Cylinder Specifications
Description 1930ES 2030ES 2630ES 2646ES 3246ES
Lift Cylinder Bore
2.8 in
(7.1 cm)
3.1 in
(7.9 cm)
3.1 in
(7.9 cm)
3.9 in
(9.9 cm)
3.9 in
(9.9 cm)
Lift Cylinder Stroke
43.2 in
(108 cm)
48 in
(122 cm)
48 in
(122 cm)
44.9 in
(114 cm)
56.8 in
(144 cm)
Lift Cylinder Rod Diameter
1.8 in
(4.5 cm)
2.1 in
(5.5 cm)
2.1 in
(5.5 cm)
2.4 in
(6 cm)
2.4 in
(6 cm)
Steer Cylinder (Stroke)
6.3 in
(16 cm)
6.3 in
(16 cm)
6.3 in
(16 cm)
6.1 in
(15.6 cm)
6.1 in
(15.6 cm)
Table 1-16. Major Component Weights
Component 1930ES 2030ES 2630ES 2646ES 3246ES
Platform
100 lbs
(45 kg)
133 lbs
(61 kg)
176 lbs
(80 kg)
Manual Platform Extension
45 lbs
(20 kg)
Arm Assembly - (Includes Lift Cylinder)
620 lbs
(281 kg)
939 lbs
(426 kg)
1,213 lbs
(550 kg)
1,645 lbs
(746 kg)
Chassis w/Wheel/Tire and Drive Assembly
1,067 lbs
(484 kg)
1,764 lbs
(800 kg)
1,554 lbs
(705 kg)
Table 1-17. Critical Stability Weights
Component 1930 ES 2030ES 2630ES 2646ES 3246ES
Counterweight(s) (CE, AUS)
582 lbs
(264 kg)
721 lbs
(327 kg)
1592 lbs
(722 kg)
1956 lbs
(887 kg)
Counterweight (ANSI, CSA, JPN) N/A N/A
721 lbs
(327 kg)
589 lbs
(267 kg)
Wheel and Tire Assembly (each) 22 lbs (9.8 kg) 42 lbs (19 kg)
Wheel/Tire and Drive Assembly (each) 117 lbs (53 kg) 162 lbs (73.4 kg)
Lift Cylinder 176 lbs(80 kg) 205 lbs (93 kg) 263 lbs (119 kg) 283 lbs (128 kg)
Batteries: (each)
220 Amp
220 Amp (used with Inverter/Charger)
245 Amp
60 lbs (27 kg)
66 lbs (30 kg)
N/A
60 lbs (27 kg)
66 lbs (30 kg)
70 lbs (32 kg)
