SECTION 5 - JLG CONTROL SYSTEM
5-26 – JLG Lift– 3121166
5.9 MACHINE MODEL ADJUSTMENT - ZAPI - 1001092456 POWER MODULE
NOTE: These settings may change in order to achieve optimal performance on a machine by machine basis.
Table 5-4. Machine Model Adjustment
(Machines with ZAPI - 1001092456 Power Module Only)
Adjustment Adjustment Range 1930ES 2030ES 2630ES 2646ES 3246ES
DRIVE
ACCEL 0.1 - 5.0 (Sec) 0.7 0.7 0.7 0.7 0.7
DECEL 0.1 - 1.0 (Sec) 0.1 0.1 0.1 0.1 0.1
MINIMUM 0 - 25% 0 0 0 0 0
MAXIMUM 0 -100% 100 100 100 100 100
ELEV. MAX. 0 - 25% 25 25 25 25 25
LIFT
ACCEL 0.1 - 5.0 (Sec) 0.5 0.5 0.5 0.5 0.5
DECEL 0.1 - 1.0 (Sec) 0.1 0.1 0.1 0.1 0.1
UP MIN 0 - 50% 20 20 20 20 20
UP MAX 0 - 100% 100 100 100 100 100
DN MIN 1 - 60% 45 45 45 45 45
DN MAX 1 - 100% 85 85 85 85 85
STEER
STATIC 0 - 100% 70 70 70 70 70
DRIVE 0 - 100% 30 30 30 30 30
ACCELERATOR
FWD MIN 2.20 - 2.40 V 2.23 2.23 2.23 2.23 2.23
FWD MAX 1.00 - 1.50 V 1.19 1.19 1.19 1.19 1.19
REV MIN 2.60 - 2.80 V 2.74 2.74 2.74 2.74 2.74
REV MAX 3.50 - 4.00 V 3.78 3.78 3.78 3.78 3.78
GROUND
HORN 87 - 107 dB 107 107 107 107 107
ALARM 87 - 107 dB 87 87 87 87 87
LOAD
ACCY 0 - 200 Kg 0 0 0 0 0
OVR DBNCE 0.0 - 5.0 Sec 3.0 3.0 3.0 3.0 3.0
OVR HOLD 0.0 - 5.0 Sec 5.0 5.0 5.0 5.0 5.0
1001115627-B
