Model Dimensions
Table 1-7. Dimensions
MODEL 1930ES 2030ES 2630ES 2646ES 3246ES
Platform Height - Elevated
18.75 ft
(5.7 m)
20 ft
(6 m)
25.8 ft
(7.9 m)
26 ft
(7.9 m)
32 ft
(9.8 m)
Platform Height - Stowed
2.9 ft
(0.9 m)
3.6 ft
(1.1 m)
4 ft
(1.2 m)
4 ft
(1.2 m)
4 ft
(1.2 m)
Working Height
25 ft
(7.6 m)
26 ft
(7.9 m)
32 ft
(9.8 m)
32 ft
(9.8 m)
38 ft
(11.6 m)
Overall Stowed Machine Height - Rails Up
6.5 ft
(2 m)
7.2 ft
(2.2 m)
7.7 ft
(2.3 m)
7.7 ft
(2.3 m)
7.7 ft
(2.3 m)
Overall Stowed Machine Height - Rails Collapsed N/A
6 ft
(1.8 m)
6.4 ft (
1.9 m)
6.4 ft
(1.9 m)
6.4 ft
(1.9 m)
Rail Height (From platform floor)
3.6 ft
(1.1 m)
3.6 ft
(1.1 m)
3.6 ft
(1.1 m)
3.6 ft
(1.1 m)
3.6 ft
(1.1 m)
Overall Machine Width
2.5 ft
(0.8 m)
2.5 ft
(0.8 m)
2.5 ft
(0.8 m)
3.7 ft
(1.2 m)
3.7 ft
(1.2 m)
Overall Machine Length - Deck Retracted
6 ft
(1.9 m)
7.5 ft
(2.3 m)
7.5 ft
(2.3 m)
8.2 ft
(2.5 m)
8.2 ft
(2.5 m)
Overall Machine Length - Deck Extended
9 ft
(2.8 m)
10.5 ft
(3.2 m)
10.5 ft
(3.2 m)
12.4 ft
(3.8 m)
12.4 ft
(3.8 m)
Platform Size - Length
6.1 ft
(1.9 m)
7.5 ft
(2.3 m)
7.5 ft
(2.3 m)
8.2 ft
(2.5 m)
8.2 ft
(2.5 m)
Platform Size - Width
2.5 ft
(0.8 m)
2.5 ft
(0.8 m)
2.5 ft
(0.8 m)
3.7 ft
(1.1 m)
3.7 ft
(1.1 m)
Platform Extension Length
3 ft
(0.9 m)
3 ft (
0.9 m)
3 ft
(0.9 m)
4.2 ft
(1.3 m)
4.2 ft
(1.3 m)
Wheelbase
5.3 ft
(1.6 m)
6.2 ft
(1.9 m)
6.2 ft
(1.9 m)
6.9 ft
(2.1 m)
6.9 ft
(2.1 m)
