JRC ECDIS User Manual

Appendix A Alert and Maintenance INFO List A-26
Message Explanation Advice
No. #n
Wing-Conning(Communi
cation failed, Main LAN)
Communication with No.
#n Wing-Conning cannot
be performed via Main
LAN.
Check the condition of No. #n Wing-Conning
and Main LAN.
If it cannot be recovered after you check the
connection of the equipment cable in
power-off status and restart, turn off the
power of the device and contact your
distributor.
No. #n
Wing-Conning(Communi
cation failed, Sub LAN)
Communication with No.
#n Wing-Conning cannot
be performed via Sub
LAN.
Check the condition of No. #n Wing-Conning
and Sub LAN.
If it cannot be recovered after you check the
connection of the equipment cable in
power-off status and restart, turn off the
power of the device and contact your
distributor.
Port Main
Propeller(invalid)
There is a format error or
a status error of the data.
Check the sensor condition.
Port Main Propeller(not
plausible)
There is a range error of
the data.
Check the sensor condition.
Port Main
Propeller(unavailable)
The data cannot be
received.
Check the condition of the sensor and the
communication path.
Position(doubtful)
The integrity of Position
cannot be verified.
Check the sensor condition. Switch to a
sensor in good condition.
Position(failed)
The Position has been
rejected by the integrity
verification.
Check the sensor condition. Switch to a
sensor in good condition.
ROT(invalid)
There is a format error or
a status error of the ROT
data.
Check the sensor condition.
ROT(unavailable) The ROT data cannot be
received.
Check the condition of the sensor and the
communication path.
Rudder #n(invalid) There is a format error or
a status error of the
Rudder data.
Check the sensor condition.
Rudder #n(not plausible) There is a range error of
Rudder data.
Check the sensor condition.
Rudder #n(unavailable) The Rudder data cannot
be received.
Check the condition of the sensor and the
communication path.
Rudder(Communication
failed, Main LAN)
Communication with
Rudder cannot be
performed via Main LAN.
Check the condition of Rudder and Main LAN.
If it cannot be recovered after you check the
connection of the equipment cable in
power-off status and restart, turn off the
power of the device and contact your
distributor.
Rudder(Communication
failed, Sub LAN)
Communication with
Rudder cannot be
performed via Sub LAN.
Check the condition of Rudder and Sub LAN.
If it cannot be recovered after you check the
connection of the equipment cable in
power-off status and restart, turn off the
power of the device and contact your
distributor.
