JRC ECDIS User Manual

A-27 Appendix A Alert and Maintenance INFO List
１
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
APP A
23
24
25
Message Explanation Advice
Sea TEMP(invalid) There is a format error or
a status error of the Water
temperature data.
Check the sensor condition. Switch to a
sensor in good condition, if available.
Sea TEMP(unavailable)
The Water temperature
data cannot be received.
Check the condition of the sensor and the
communication path. Switch to a sensor in
g
ood condition, if available.
Ship's
clock(Communication
failed, Main LAN)
Communication with
Ship's clock cannot be
performed via Main LAN.
Check the condition of Ship's clock and Main
LAN.
If it cannot be recovered after you check the
connection of the equipment cable in
power-off status and restart, turn off the
power of the device and contact your
distributor.
Ship's
clock(Communication
failed, Sub LAN)
Communication with
Ship's clock cannot be
performed via Sub LAN.
Check the condition of Ship's clock and Sub
LAN.
If it cannot be recovered after you check the
connection of the equipment cable in
power-off status and restart, turn off the
power of the device and contact your
distributor.
SLC1 - #n
(Communication failed,
Main LAN)
Communication with
SLC1-#n cannot be
performed via Main LAN.
Check the condition of SLC1-#n and Main
LAN.
If it cannot be recovered after you check the
connection of the equipment cable in
power-off status and restart, turn off the
power of the device and contact your
distributor.
SLC2- #n
(Communication failed,
Sub LAN)
Communication with
SLC2-#n cannot be
performed via Sub LAN.
Check the condition of SLC2-#n and Sub
LAN.
If it cannot be recovered after you check the
connection of the equipment cable in
power-off status and restart, turn off the
power of the device and contact your
distributor.
Stbd Main
Propeller(invalid)
There is a format error or
a status error of the data.
Check the sensor condition.
Stbd Main Propeller(not
plausible)
There is a range error of
the data.
Check the sensor condition.
Stbd Main
Propeller(unavailable)
The data cannot be
received.
Check the condition of the sensor and the
communication path.
Stern Thruster #n
(invalid)
There is a format error or
a status error of the data.
Check the sensor condition.
Stern Thruster #n (not
plausible)
There is a range error of
the data.
Check the sensor condition.
Stern Thruster #n
(unavailable)
The data cannot be
received.
Check the condition of the sensor and the
communication path.
Time(invalid) There is a format error or
a status error of the Time
data.
Check the sensor condition. Switch to a
sensor in good condition, if available.
Time(unavailable) The Time data cannot be
received.
Check the condition of the sensor and the
communication path. Switch to a sensor in
g
ood condition, if available.

JRC ECDIS Specifications

General

Display Type	LCD
Radar Overlay	Yes
AIS Integration	Yes
Operating Temperature	-15°C to +55°C
Chart Format	S-57, S-63
Power Supply	24V DC
Interfaces	Ethernet, USB
Compliance	IMO
