Appendix B Menu List and Materials B-76
B.6.1 Symbol
Object name
Icon button
display example
Remarks
Circle
Triangle
Square
Diamond
Multiple mark
Caution symbol
Warning symbol
Alert symbol
Airport/airfield
Anchor berth
Anchorage area
Beacon, cardinal
Beacon, isolated danger
Beacon, lateral
Beacon, safe water
Beacon, special purpose/general
Berth
Building, single
Built-up area
Buoy, cardinal
