B-77 Appendix B Menu List and Materials
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
APP B
24
25
27
APP C
Object name
Icon button
display example
Remarks
Buoy, installation
Buoy, isolated danger
Buoy, lateral
Buoy, safe water
Buoy, special purpose/general
Cargo transhipment area
Caution area
Checkpoint
Coastguard station
Control point
Crane
Current - non-gravitational
Dam
Daymark
Distance mark
Dumping ground
Fishing facility
Fog signal
Fortified structure
Gate
Harbour facility
Hulk
Incineration area
Land area
Land elevation
Land region
Landmark
Light
