B-127 Appendix B Menu List and Materials
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
APP B
24
25
27
APP C
Category name Object name
Icon button display
example
Alert generated when
the own ship approaches
the object
Beacon in
general
2 cones point downward No alert
2 cones base to base No alert
2 cones point to point No alert
Sphere No alert
2 spheres No alert
Cylinder No alert
Board No alert
Cube point up No alert
X-shape No alert
Upright cross No alert
Besom point down No alert
Besom point up No alert
T-shape No alert
Lattice beacon (No object name) No alert
Cone point up No alert
Cone point down No alert
