Appendix B Menu List and Materials B-128
Category name Object name
Icon button display
example
Alert generated when
the own ship approaches
the object
Lattice beacon 2 cones point upward No alert
2 cones point downward No alert
2 cones base to base No alert
2 cones point to point No alert
Sphere No alert
2 spheres No alert
Cylinder No alert
Board No alert
Cube point up No alert
X-shape No alert
Upright cross No alert
Besom point down No alert
Besom point up No alert
T-shape No alert
Beacon tower (No object name) No alert
Cone point up No alert
