JRC ECDIS User Manual

Appendix B Menu List and Materials B-166
e) Ellipse (line)
Line Content Description Import
m // (space) Fixed string
LINE_ELLIPSE Fixed string
+1 // (space) Fixed string
Comment Fixed string
+2 // (space) Fixed string
Base Point-Lat Fixed string
, Fixed character
, Fixed character
, Fixed character
Base Point-Lon Fixed string
, Fixed character
, Fixed character
, Fixed character
Horizontal Radius [nm] Fixed string
, Fixed character
Vertical Radius [nm] Fixed string
+3 LINE_ELLIPSE Fixed string 
+4 Comment Comment 
+5 Reference Position Latitude (degrees) 35 
, Fixed character 
Reference Position Latitude (degrees.minutes) 35.123 
, Fixed character 
Reference Position Latitude Sign (N/S) N 
, Fixed character 
Reference Position Longitude (degrees) 139 
, Fixed character 
Reference Position Longitude
(degrees.minutes)
48.234 
, Fixed character 
Reference Position Longitude Sign (E/W) E 
, Fixed character 
Horizontal Radius [NM] 2.0 
, Fixed character 
Vertical Radius [NM] 1.5 
