JRC ECDIS User Manual

B-167 Appendix B Menu List and Materials
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
APP B
24
25
27
APP C
f) Arc
Line Content Description Import
m // (space) Fixed string
ARC Fixed string
+1 // (space) Fixed string
Comment Fixed string
+2 // (space) Fixed string
Base Point-Lat Fixed string
, Fixed character
, Fixed character
, Fixed character
Base Point-Lon Fixed string
, Fixed character
, Fixed character
, Fixed character
Radius [nm] Fixed string
, Fixed character
Start Angle[deg] Fixed string
, Fixed character
End Angle[deg] Fixed string
+3 ARC Fixed string 
+4 Comment Comment 
+5 Reference Position Latitude (degrees) 35 
, Fixed character 
Reference Position Latitude (degrees.minutes) 35.123 
, Fixed character 
Reference Position Latitude Sign (N/S) N 
, Fixed character 
Reference Position Longitude (degrees) 139 
, Fixed character 
Reference Position Longitude
(degrees.minutes)
48.234 
, Fixed character 
Reference Position Longitude Sign (E/W) E 
, Fixed character 
Radius [NM] 2.0 
, Fixed character 
Start Radius [deg] 120.0 
, Fixed character 
End Radius [deg] 180.0 

JRC ECDIS Specifications

General

Display Type	LCD
Radar Overlay	Yes
AIS Integration	Yes
Operating Temperature	-15°C to +55°C
Chart Format	S-57, S-63
Power Supply	24V DC
Interfaces	Ethernet, USB
Compliance	IMO
