Chapter 5 VARIOUS FUNCTIONS
114
Press 1 time, recover 8 seconds later: Performing “Delete Chart Temporarily” while select the mode, chart
is disappeared for 8 seconds and displayed again.
Performing “Delete Echo Temporarily” while select the mode, radar
echo image is disappeared for 8 seconds and displayed again.
5.29 MARK SETTING
Set the size, color and type for marks (about the mark function, see “5.9 MARK”).
Only marks of a specific color or type can be displayed.
5.29.1 MARK SIZE
Select the size of mark.
5.29.2 MARK COLOR
Select the color of mark.
The color of mark can be selected from following 7 colors.
White/Cyan/Blue/Green/Yellow/Pink/Red
Display Mark Color/Type
(This image is Display Mark Type)
䐡 Select each menu.㻌
Mark Size
䐟 Press the MENU button.㻌䐠 Select “Mark.”㻌
Mark Color
Mark Type
If “Mark List” is selected,
the list of marks is open.
See 5.29.6
To
5.29.4
5.29.5
To Next Page
