Chapter 13 SPECIFICATIONS
13.3 EQUIPMENT OUTLINE
This equipment is a marine radar for vessels and work boats which consists of the display unit including
12-inch SVGA color LCD Monitor unit, Keyboard unit, radar processing circuit, TT processing circuit,
AIS processing circuit and consists of the 2ft/3.9ft/4ft/6ft scanner unit. 2ft scanner unit is radome type.
3.9ft/4ft/6ft scanner units are open-array type. The operation can be realized intuitive and simple.
13.3.1 CONFIGULATION
1) Display unit NCD-2364
ዘ Integrated the 12 inch SVGA color LCD Monitor unit, Keyboard unit and Processing unit
2) Scanner unit
ዘ X-band 2ft (4kW) radome type NKE-2043
ዘ X-band 3.9ft (6kW) open-array type NKE-2063A/AHS
ዘ X-band 4ft (10kW) open-array type NKE-2103-4/4HS
ዘ X-band 6ft (10kW) open-array type NKE-2103-6/6HS
13.3.2 FEATURE
1) The screen resolution is 800x600dots (SVGA).
2) Highly efficient signal processing with FPGA.
3) TT function is prepared with DSP.
4) Real-time head-up function, AIS display function and chart drawing function with CPU.
13.3.3 RADAR MODEL
JMA-3404 2ft (4kW) Standard model scanner: NKE-2043
JMA-3406 3.9ft (6kW) Standard model scanner: NKE-2063A
JMA-3406HS 3.9ft (6kW) High speed model scanner: NKE-2063AHS
JMA-3411-4 4ft (10kw) Standard model scanner: NKE-2103-4
JMA-3411-4HS 4ft (10kw) High speed model scanner: NKE-2103-4HS
JMA-3411-6 6ft (10kW) Standard model scanner: NKE-2103-6
JMA-3411-6HS 6ft (10kW) High speed model scanner: NKE-2103-6HS
