Chapter 10 MAINTENANCE AND CHECK
10.5 FAULT FINDING
10.5.1 ALARMS AND OTHER DISPLAY LISTS
If any of the following alarm occurs, the system displays the alarm message in red in order to attract the
attention of operator. Other messages are displayed with the suitable color which is yellow or blue
depending on the level of message importance.
Alarm:
Red 䈄 Collision-related Alarm


䈄 Navigation Alarm

 䈄 System Alarm
Caution:
Yellow 䈄 System Warning
Status:
Blue 䈄 Operation Information
The following table shows alarms and other indications the system displays.
Table 10.5.1 Alerts and other display lists
Alarm Code
*Screen notation
Alarm Name Class Description
S001 Alarm Error Alarm
Cannot send the alarm because of insufficient message
buffer for alarm task.
S002 Scanner(AZI) Alarm
The BP error bit of scanner communication data is set.
S003 Scanner(HL) Alarm
The BZ error bit of scanner communication data is set.
S004 Scanner(MHV) Alarm
The high-voltage modulator error bit of scanner
communication data is set.
S005 Scanner(Time out) Alarm
No reply from the scanner after data communication.
S006 Scanner(Data) Alarm
Collision occurs when transmitting data to the scanner.
Checksum of the received data is different.
S007 Scanner(EEPROM) Alarm
Stored value error is returned from the scanner when the
initial adjustment data is requested.
The save operation is not completed when data save is
requested to scanner EEPROM.
S008 Scanner(Heater) Alarm
The MAG heater voltage error bit of scanner
communication data is set.
S009 Scanner(Reverse) Alarm
The Scanner reverse bit of scanner communication data is
set.
S010 Scanner(Video) Alarm
The VIDEO error bit of scanner communication data is set.
S011 Scanner(Trigger) Alarm
The TRIGGER error bit of scanner communication data is
set.
S012
Scanner(Safety-SW
Off)
Alarm
The SAFETY SWITCH OFF bit of scanner communication
data is set.
D001 GPS Port Alarm
Serial driver error occurs.
D002 NMEA1 Port Alarm
Serial driver error occurs.
D003 NMEA2 Port Alarm
Serial driver error occurs.
D004 NMEA3 Port Alarm
Serial driver error occurs.
D005 Scanner Port Alarm
Serial driver error occurs.
D006 Keyboard Alarm
Serial driver error occurs.
