Chapter 1 INSTALLATION

1.4.1 NKE-2043 SCANNER (2 FEET)

Set the cable inlet side to stern.

(Any direction is possible to install and possible to initial setup, but it is better selection to select the cable

length must be minimize along the mast.)

Ship heading

bow stern

Fig. 1-4-1-1

 Open radome

Loosen the screws by using box spanner tool, then you can lift up the radome.

Fig. 1-4-1-2

HORN ANNTENNA

(2FT)

CABLE INLET

RECEIVER

Loosen the screws

(6 points)
