Chapter 8 DETAIL PERFORMANCE

171

8.7.7 USB FORMAT

It may take long time to access USB flash memory during transmission.

We recommend that you use USB flash memory during standby.

࣭

During formatting, please do not disconnect the USB flash memory.

࣭

Quick format does not support.

Insert USB flash memory to USB port.

Note:

It takes time to format the USB flash memory. Format time is very similar to the time you want to format

the PC.

([HFXWH



WKLV



IXQFWLRQ



$UH



\RX



VXUH"


