Chapter 2 THE BASIC OPERATION
Chapter 2 THE BASIC OPERATION
If the basic adjustment is made by the serviceman beforehand, please run it as it is.
(In the case of no adjustment is done by the serviceman beforehand, you had better grasped the operation of
this radar through referring to Chapter 5, then please perform the initial settings that are listed in Chapter 7.)
2.1 PANEL AND SCREEN DISPLAY LAYOUT
Numerical Information
Range Rings
Heading Line
Adjustment bar
Range
Numerical Info.
Speed
Heading
Bearing Mode Own Ship Movement
Sensitivit
Tar
et Enhance
Rain/Snow Clutter
Suppression
Guard Zone1
Own Track Length
Alarm
Guard Zone1
System Running
Animation
MOB
Anchor Watch
Screen Capture
Vector Length
Guard Zone2
Cursor
Pulse Width
Anchor Watch
Process
MOB
Scanner state
Function Mode
Guard Zone2
Sea Clutter
Suppression
IR
Trail Length
Wind
Speed/Direction
