A-11
APPENDIX
MENU FUNCTION LIST
Main Menu
Item Setting Contents
1. User
1. USER1 short press Release / Cancel
2. USER2 short press Release / Cancel
3. USER1 long press Release / Cancel
4. USER2 long press Release / Cancel
2. RADAR Echo
1. Pulse Width SP1 / SP2 / MP1 / MP2 / LP1 / LP2 / LP3
2. IR OFF / Low / Middle / High
3. Target Enhance OFF / Leve1 / Level2 / Level3
4. Process
OFF / 3Scan CORREL / 4Scan CORREL / 5Scan CORREL / Remain / Peak
Hold
5. Zoom Mode OFF / Zoom x2 / Zoom Circle
6. Video Noise Rejection OFF / Level1 / Level2 / Level3
7. Video Latitude Narrow / Normal / Wide1 / Wide2 / Max
3.Tune Manual / Auto
4. Marker
1. EBL1 Setting
1. Floating Off / Screen Fix / Lat/Lon Fix
2.Bearing Mode True / Relative
2. EBL2 Setting
1. Floating Off / Screen Fix / Lat/Lon Fix
2. Bearing Mode True / Relative
3. Parallel Cursor
1. Range Scale Link Off / On
2. Floating Off / Screen Fix / Lat/Lon Fix
3. Bearing Mode Angle Fix / Screen Fix / Heading Fix
4. One / Both Sides One Side / Both Sides
5. Display For Individual Line1 Off / On
6. Display For Individual Line2 Off / On
7. Display For Individual Line3 Off / On
8. Display For Individual Line 4 Off / On
9. Display For Individual Line5 Off / On
10. Display For Individual Line 6 Off / On
11. Display For Individual Line 7 Off / On
4. VRM Unit NM / km / sm / Link Range
5. Cursor Mode
1.Bearing Mode True / Relative
2.Unit NM / km / sm / Link Range
3.Size Small / Large
4.Pattem
Thin Cross / Thin Cross(Empty on Center) / Thick Cross / Thick Cross(Empty
on Center)
6. Range Ring Off / On
5. Set Own Ship Movement
1. TM/RM RM / TM
2. Bearing Mode Head Up / North Up / Course Up / Course Up Reset
6. Trails
1. Threshold Level1 / Level2 / Level3 / Level4
2. Time/All Combine Off / On
To Next Page
