Chapter 10 MAINTENANCE AND CHECK
Alarm Code
*Screen notation
Alarm Name Class Description
D007 GYRO(Time Out)
Alarm
For heading equipment=GYRO, cannot receive valid
sentences (including checksum error) which had been
received properly.
D008 Log(Time Out)
Alarm
For speed equipment=log, cannot receive valid sentences
(including checksum error) which had been received
properly.
D009 GYRO(Data)
Alarm
For heading equipment=GYRO, the GYRO error bit of
NSK communication data is set.
D010 Log(Data)
Alarm
For speed equipment=log, the LOG error bit of NSK
communication data is set.
D011 Heading(Time Out)
Alarm
For heading equipment=compass, cannot receive valid
NMEA bearing sentences (including checksum error)
which had been received properly.
D012 Heading(Data)
Alarm
For heading equipment=compass, cannot receive valid
NMEA bearing data which had been received properly.
D013 2AXG(Time Out)
Alarm
For speed equipment =2-axis log, cannot receive valid
VBW sentences(including checksum error) which had
been received properly.
D014 2AXG(Data)
Alarm
For speed equipment=2-axis log, cannot receive valid
VBW ground data which had been received properly.
D015 GPS(Time Out)
Alarm
Cannot receive valid GPS sentences(including checksum
error) which had been received properly.
D016 GPS(Position)
Alarm
Cannot receive valid position data which had been
received properly.
D017 GPS(Datum)
Alarm
Cannot receive valid geodetic data which had been
received properly.
D018 GPS(Speed)
Alarm
For Speed equipment=GPS, cannot receive valid speed
data which bad been received properly.
D019 GPS(Status)
Alarm
Received GPS fixing status error (invalid) data
D020 Depth(Time Out)
Alarm
Cannot receive valid depth sentences (including
checksum error) which had been received properly.
D021 Depth(Data)
Alarm
Cannot receive valid depth data which had been received
properly.
D022 TEMP(Time Out)
Alarm
Cannot receive valid water temperature sentences which
had been received properly.
D023 TEMP(Data)
Alarm
Cannot receive valid water temperature data which had
been received properly.
D024 Wind(Time Out)
Alarm
Cannot receive valid wind direction/wind velocity
sentences (including checksum error) which had been
received properly.
D025 Wind True(Data)
Alarm
Cannot receive valid wind direction/wind velocity (true)
data had been received properly.
D026 Wind Relative(Data)
Alarm
Cannot receive valid wind direction/wind velocity (relative)
data had been received properly.
D027 Turn(Time Out)
Alarm
Cannot receive valid turning ratio sentences (including
checksum error) which had been received properly.
D028 Turn(Data)
Alarm
Cannot receive valid turning ratio data which had been
received properly.
D029 Rudder(Time Out)
Alarm
Cannot receive valid steering direction sentences
(including checksum error) which had been received
properly.
D030 Rudder(Data)
Alarm
Cannot receive valid steering direction data which had
been received properly
