Chapter 10 MAINTENANCE AND CHECK
Alarm Name *Screen notation Class Description
In Operation Status
This operation is disabled due to another operation
- Setting enable/disable and level during guard zone
creation
- Operations for on/off during VRM range setting
- Operations for PRF tuning during manual tuning
operations
- Setting for automatic/manual mode during
manual tuning Operations
- Operations for manual tuning during PRF tuning
operation
No HDG/POSN Data Status
Cursor operations when own heading or
latitude/longitude is disabled
- MOB input
- Event mark input
- Inputting/erasing/moving marks
- Inputting/erasing/moving/inserting lines
- AIS numerical display/destination ship/retrieved
vessel Selection
- Creating latitude/longitude guard zone.
- TLL transmission for cursor.
Not Allowed Status
Operations for inserting by selecting the end point in the
line list.
Operations for switching to H-UP during TM (When heading
is not available, temporarily changed to RM H-Up,
therefore, message is disabled.)
Range Scale Limit Status
Operations functionally restricted for certain range.
Off center operations in range where off center is not
available.
TM setting operations in range where TM setting is not
available.
No Valid Data Status
Operations without data.
Scanner Standby Status
The functions which are available only during transmitting
are operated during standby (or preheating).
- Setting Timed TX to on.
- Cursor operations during standby (no graphic display
is available).
- Custom position setting for off center.
- Inputting/erasing/moving marks
- Inputting/erasing/moving/inserting lines
- TT acquisition/release/numerical display selection.
- Guard zone creation
High Temperature Caution
The temperature in the radar antenna is 80 Υ or higher.
High Latitude Status
Operations for the position of latitude 80 degrees or more.
- MOB input.
- Event mark input.
- Input/moving marks.
- Input/moving/inserting lines.
- Creating latitude/longitude alarm area.
Invalid Version Status
Program is loading a file with an incompatible version.
- Internal setting
- Marks/lines
- Option languages
- STC curve
TT(Max Target) Status
Detects when trying to automatically capture the 31st or
more targets.
TT(Out of Range) Status
TT is too far to be tracked.
MAX Range Scale Status
Range up operations at the maximum range.
MIN Range Scale Status
Range down operations at the minimum range.
