Chapter 13 SPECIFICATIONS
(13) Power Consumption:
In calm wind Maximum (Velocity of the wind: 100 kn)
JMA-3404 Approx. 60W Approx. 60W
JMA-3406 Approx. 85W Approx. 180W
JMA-3406HS Approx. 85W Approx. 230W
JMA-3411-4 Approx. 100W Approx. 210W
JMA-3411-4HS Approx. 100W Approx. 360W
JMA-3411-6 Approx. 100W Approx. 210W
JMA-3411-6HS Approx. 100W Approx. 360W
(14) Range of power supply voltage fluctuation
+10.8 to 31.2 VDC (Display Unit) (JMA-3404, JMA-3406)
* JMA-3404/JMA-3406 input voltage upper limit is +30%
of DC24V.
+21.6 to 31.2 VDC (Display Unit)
(JMA-3406HS, JMA-3411-4/4HS/6/6HS)
DC12/24V -10%/+30%
(15) Pre heat time Approx. within 1min30sec.
(16) Display unit Refer to Display unit Specifications
(17)Inter-unit Cables Option
Length selectable (CFQ6912-5/10/15/20/30m)
When using JMA-3404 and JMA-3406 with 12V DC, the
maximum cable length is 20m or less.
